Li-ion & Li-Polymer Rechargeable Batteries



Cylindrical Li-ion cells

Cylindrical cells are generally used for various digital products, we target our products for your ease and joyfulness......



Cylindrical Series

Model Nominal Capacity(mAh) Nominal Voltage(mAh) Dimension(mm) Weight(g)
Diameter Height
UFR18650-1.1 1100 3.2 18.2 65.2 38
UFR26650-2.3 2300 3.2 26.5 65.2 78
UFR32900-4.4 4400 3.2 32.5 90.5 188
UFR22650-1.4 1400 3.2 22.5 65.3 62
UNR18650-1.3 1300 3.6 18.4 65 45
UNR18650-1.5 1500 3.6 18.4 65 45
UNR18650-2.0 2000 3.6 18.3 65 45
UNR26700-3.4 3400 3.8 26.3 70.5 100
UNR26700-5.0 5000 3.6 26.3 70.5 101
UNR18650-2.2V 2200 3.7 18 65 48
UNR18650-2.2 2200 3.6 18 65 48
UNR18650-2.6 2600 3.7 18 65 48
UCR18650-2.8V 2800 3.75  18 65 48
UCR18650-3.0V 3000 3.8 18 65 48



High-power battery cells
Suppo is your reliable High-Power battery supplier, not only power……


High Power Series

Model Nominal Capacity(mAh) Nominal Voltage(mAh) Dimension(mm) Weight(g)
OD/Thickness Width Height
UFR18650-1.1P 1100 3.2 18.2 65.2 38
UFR26650-2.3P 2300 3.2 26.5 65.2 78
UFR32900-4.4P 4400 3.2 32.5 90.5 188
UFR22650-1.4P 1400 3.2 22.5 65.3 62
UNR18650-1.3P 1300 3.6 18.4 65 45
UNR18650-1.5P 1500 3.6 18.4 65 45
UNR18650-2.0P 2000 3.6 18.3 65 45
UNR18650-3.4P 3400 3.8 26.3 70.5 100
UNR26700-5.0P 5000 3.6 26.3 70.5 101
UMP2770116-10P 10000 3.7 27.5 70.5 126 340
UMP27140120-20P 20000 3.7 27.5 140.5 135 710
UMP36130170A-50P 50000 3.7 36.5 130.5 185 1480
UMP7068280P-10P 10000 3.7 7.4 68.8 280 200
UMP64110227P-10P 10000 3.7 6.55 109.5 229 280
UMP82117300P-20P 20000 3.7 8.5 117 305 550



 LiFePO4
LiFePO4 cells usually built into battery pack, suitiable for e-bike, UPS, Power tools……


LiFePO4 Series

Model Rated Voltage Typical(mAh) Min.(mAh) Demension (mm) Weight (g)
Diameter*Hight
UFR14500-0.5 3.2 500 450 14.2 50.5 16.5±1
UFR18650-1.4 3.2 1400 1300 18.2 65.2 42±1
UFR18650-1.1P 3.2 1100 1000 18.2 65.2 38±1
UFR26650-3.0 3.2 3000 2900 26.5 65.2 80±1
UFR26650-2.3P 3.2 2300 2200 26.5 65.2 78±1
UFR32900-4.9 3.2 4900 4850 32.5 90.5 188±5
UFR32900-4.4P 3.2 4400 4300 32.5 90.5 188±5
UFR42120-12 3.2 12000 10000 42.5 120.5 390±5
UFR22650-2.0 3.2 2000 1900 22.5 65.3 62±1
UFR22650-1.4P 3.2 1400 1300 22.5 65.3 62±1



Li-polymer series cells
More flexible to meet customers' requirements......


Li-Polymer Series


Model Rated Capacity Min(mAh) Rated Voltage Internalresistance(mAh) Thickness
Maxt(g)
Width
Max(g)
Height Max(g) Weight(g)
UCS6462114-4.8 4800 3.7 <50 6.4 62 114 90.6
UCS7045150-4.6 4600 3.7 <60 7 45 147.5 177
UCS716583-4.2 4200 3.7 <40 6.9 64.5 81.5 79.2
UCS4270125-4.0 4000 3.7 <60 4.2 70 125 75.5
UCS7050105-3.8 3800 3.7 <50 6.7 49.5 103 71.7
UCS606198-3.5 3500 3.7 <40 6.2 61.5 98.5 63.8
UCS4564107-3.4 3400 3.7 <50 4.5 64 107 64.2
UCS4555128-3.2 3200 3.7 <40 4.2 54.5 128.5 61
UCS6050105-3.0 3000 3.7 <50 5.6 49.5 103 56.6
UCS403048-0.6 600 3.7 <80 4.2 30.5 48.5 11.5
UCS582245-0.55 550 3.7 <80 5.8 22.5 45.5 11
UCS602044-0.54 540 3.7 <80 6.3 20.5 44.5 10.1
UCS733043-1.0 1000 3.7 <60 7.5 32 42.5 17.5
UCS603450-1.0 1000 3.7 <60 6 34.5 50.5 18.9
UCS432595-1.0 1000 3.7 <60 4.5 25.5 95.5 18.5
UCS403562-0.98 980 3.7 <80 4 30.5 62.5 17.1
UCS432777-0.95 950 3.7 <80 4.3 27 77.5 17.9
UCS603048-0.9 900 3.7 <60 6.2 30.5 48 16.5
UCS383758-0.9 900 3.7 <60 4 37.5 58 17
UCS353282-0.9 900 3.7 <60 3.5 32 80.5 18
UCS363759-0.86 860 3.7 <60 3.8 37.5 59.5 15.6
